Power Source |
220 – 240 V AC, 50/60 Hz |
Rated Output |
60 W |
Power Consumption |
100 W (rated output), 18 W (EN60065) |
Frequency Response |
20 Hz – 20 kHz |
Distortion |
1 % or less |
Input |
MIC 1, 2: -52 dB*, 600 Ω, unbalanced, ø6.3 phone jack (2P)
AUX 1, 2: -20 dB*, 10 kΩ, unbalanced, RCA pin jack |
Output |
SPEAKER OUT: Low impedance (2 x 8 Ω or 1 x 4 Ω), Push-in terminal |
S/N Ratio |
MIC 1, 2: 60 dB or more
AUX 1, 2: 70 dB or more |
Protection |
Power Supply Thermal Shut down
Power Amplifier Thermal Shut down
Power Amplifier Over Current
Each protection will be restored automatically |
Indicator |
Power LED (Blue) |
Operating Temperature |
0 ℃ to +40 ℃ |
Operating Humidity |
90 %RH or less (no condensation) |
Finish |
Case: Steel plate, off-white, paint
Knob: ABS resin, black |
Dimensions |
210 (W) × 70.6 (H) × 180 (D) mm |
Weight |
1.6 kg |
Accessory |
Wall Mounting Pattern Paper x 1 |
